Product description
JP series integrated outdoor distribution tanks, a multifunctional integrated outdoor distribution unit, such as metrology, out-lines and no functional compensation, with short circuits, overloads, over-voltage, leak protection, small size, exterior beauty, economic utility, installed on the pole transformer poles, are a new generation of ideal electricity distribution products for urban and rural grid adaptation.
Model designation
Environmental conditions for use
Ambient temperature: -25°C-+40°C.
Relative humidity of air: The daily average is not more than 90% and the monthly average is not more than 90%.
Altitude: no more than 2500m.
Installation at sites free from severe vibrations and shocks, and non-corrosive gases.
Structural characteristics
The enclosure is available in vertical and horizontal configurations. It uses 2mm high-quality stainless-steel sheet formed by multiple bends, or a stainless-steel double-sandwich honeycomb composite panel offering flame retardancy, environmental compatibility, thermal insulation and condensation resistance. A special welding process gives high overall strength and a smooth, mirror-like surface without visible weld marks. Internal mounting beams or plates are hot-dip galvanized to resist corrosion for twenty years. Front and rear doors facilitate operation and servicing. Each door has resilient, aging-resistant seals and both exposed and concealed locks; the exposed lock has a rain cover to resist blockage and corrosion. The metering compartment is fully enclosed and fitted with a lead-sealing device. Side cable-entry conduits prevent rain and foreign-object ingress; ventilation and cable-exit holes are provided at the bottom, with ventilation passages and wire mesh at the top. The enclosure resists water, rust, dust and foreign objects, with protection rating IP54.
Information on orders
1. Product type, quantity.
2. Product structure (on-line, on-site).
3. Models and technical parameters of the main components.
4. Other special requirements.
