GK-ATS dual-power distribution box

GK-ATS dual power distribution tanks are applicable to power plants and industrial and mining enterprises to exchange three-way, three-way, three-way, three-way, three-way, five-way power distribution systems with a voltage of 500 V and below. GK-ATS dual power distribution tank is an in-house unit installed against the wall and prescreened.

Ambient temperature: -50°C to +40°C, with a 24-hour average not exceeding +36°C.

Altitude: no more than 2500m.

Relative humidity: not more than 50 per cent of the surrounding air moisture at +40°C; High relative humidity (e.g. 90 per cent at +20°C) is possible at lower humidity, taking into account that temperature changes allow for moderate condensation.

Equipment shall be installed at a gradient not exceeding 5° with a vertical surface and shall be installed at a site free from severe vibration, shock and corrosion.

Note: If the above conditions cannot be met, the user may consult with the company if it has special requirements.

Two-power distribution cabinets, in-house and wall-based, open-door distribution. Its basic structure is made of steel plate bends and angular steel welds. A knife switch handle may be installed on the front-right side for power cut-off and connection operations, an operating button may be installed on the door of the box, a signal light and display instrument, and when the case is opened, the interior equipment of the distribution box is all open and accessible for overhaul and maintenance. This tank is equipped with air breakers, which are protected as short circuits, as well as contact and heat relays. The door and the shell are welded with a snail to the ground to ensure reliable connection.
